Solved

Work Order Planning Gantt - custom fields

  • September 19, 2024
  • 1 reply
  • 55 views
AveTonitM
Hero (Partner)
Forum|alt.badge.img+10

Can work Order Planning gantt in IFS Cloud 24R1 be enriched with custom fields?

I have a requirement where work order planners need to plan and schedule work orders based on Equipment Object groups. Object group is not visible in the gantt view, so my intention was to add it as a custom field with page designer. However there is no list of attributes in the page designer.



Best answer by AveTonitM

For those who have similar needs to enrich the standard Work Order Planning gantt, I found a way to add data columns with entity columns that exist in the ActiveSeparate entity, but for some reason not available in the standard gantt

  1. Open Work Order Planning Gantt, page designer editor
  2. In Page Desinger go to “WO Planning Gantt Chart” → datagrid → Columns
  3. press the + icon
  4. add a new attribute. Use the attributes that exist in the entity. One cannot select available attributes from a list so you have to check the exact attributes from the entity
  5. Enter a label and name for the new attribute. Save and publish.



-Toni-

1 reply

AveTonitM
Hero (Partner)
Forum|alt.badge.img+10
  • AveTonitM
  • Author
  • Hero (Partner)
  • 171 replies
  • Answer
  • November 5, 2025

For those who have similar needs to enrich the standard Work Order Planning gantt, I found a way to add data columns with entity columns that exist in the ActiveSeparate entity, but for some reason not available in the standard gantt

  1. Open Work Order Planning Gantt, page designer editor
  2. In Page Desinger go to “WO Planning Gantt Chart” → datagrid → Columns
  3. press the + icon
  4. add a new attribute. Use the attributes that exist in the entity. One cannot select available attributes from a list so you have to check the exact attributes from the entity
  5. Enter a label and name for the new attribute. Save and publish.



-Toni-
